Yamaha SWR2100P-5G L2 Switch
- The SWR2100P series network switch equipped with ten RJ45 ports.
- Brand:
- Product Code:SWR2100P-5G
The SWR2100P series network switch equipped with five RJ45 ports.
- Ports available for PoE power supply: 1-4 / Up link port: 5 port
- Maximum 30W can be supplied from each PoE-compliant port (All ports 70W)
| SWR2100P-5G | ||
|---|---|---|
| LAN port | Standard | IEEE802.3 (10BASE-T/100BASE-TX/1000BASE-T) |
| Number of ports | 5 ports | |
| Ports available for PoE power supply | 4 ports (port 1–4) | |
| PoE standards | IEEE 802.3at | |
| Power supply system | Alternative A | |
| Maximum power supply | Per port | 30W (Varies depending on the power consumption class of each connected device.) |
| All ports | 70W | |
| Compatible PoE powered devices | PoE powered devices that comply IEEE 802.3af standards or IEEE 802.3at standards | |
| Switches | CONFIGURATION switches for modifying the settings (L2MS switch, Flow control switch, Auto MIDI/MIDI-X switch, Loop detection switch, energy save mode switch) | |
| Indicators | POWER, PoE LIMIT, LINK/ACT, SPEED, PoE STATE (x16) | |
| Operating environment | Ambient temperature: 0 to 40 °C, Ambient humidity: 15 to 80% (no condensation) | |
| Storage environment | Ambient temperature: -20 to 50 °C, Ambient humidity: 10 to 90% (no condensation) | |
| Power supply voltage, frequency | AC100 V to 240 V, 50 Hz/60 Hz | |
| Power consumption | 86 W | |
| Dimensions | W | 220 mm |
| H | 40.5 mm | |
| D | 250 mm | |
| Weight | 1.6 kg | |
| Accessories | Owner’s Manual; power cord; power cord clamp; feet Controls and | |
