Product Code:PSRE583
Next Level Performance + Expression
Designed for the performer, the Yamaha PSR-E583 61-key portable keyboard is packed with features, including a wide assortment of Voices and Styles, and optimized for global music-making. The intuitive control panel and illuminated buttons ensure easy access to functions, putting control and self-expression right at your fingertips.
FEATURES
WIDE COVERAGE SOUNDS
Play Any Song, Any Genre, Any Time.
With a massive range of Voices and Style presets, play any song or genre – even requests from the audience – with a touch of button! Featuring 890 different Voices, including electric piano, organ, vibraphone and strings, and 345 preset Styles, unleash your creativity on stage or at home.
VOICES
The PSR-E583 expands on previous generations with an increased internal storage capacity that allows Yamaha to provide more, higher-resolution instrument Voices. Enjoy 890 realistic, expressive instrument sounds from here and around the world with pro-level sound quality.
STYLES
Choose from 345 automatic accompaniment Styles including rock, dance, and jazz as well a wide range of musical genres from around the world. Experience the thrill of playing in your very own band as the Styles respond to your left hand with just the right rhythms, bass, and chords.
WORLD CONTENT
Piano. Organ. Igbo Drum. All included. The PSR-E583 is designed to support music across the globe. From Afrobeats featuring Igbo instruments, to reed instruments and percussion for that distinctly South American sound, to traditional organ Voices for worship, the PSR-E583 is designed for your local sound.
SUPER ARTICULATION LITE
SUPER ARTICULATION LITE Voice faithfully recreates the sounds of non-keyboard instrument, like the scratch of the strings of a guitar or the performer’s breath when playing a wind instrument.
DSP EFFECTS
Take your music to the next level with the powerful DSP effects engine, featuring 41 DSP1 and 12 DSP2 effects. These effects transform instrument Voices by enhancing tone, adding texture, and delivering expressive, realistic sound, as well as provide layering and accompaniment parts for more sonic flexibility. With a single press of the DSP button, toggle effects on or off instantly, perfect for dynamic performance control.
MIDI SONG TO STYLE APP
Transform MIDI Files into Your Personalized Style.
Automatically generate style data from your existing MIDI song library. Easily change standard MIDI files into dynamic, full-fledged Styles, complete with intros, endings, and transitions.
QUICK SAMPLING
Get the Music Started Quickly.
Explore your creativity with the Quick Sampling function, delivering the ability to record a short musical phrase and assign it to the Quick Sampling button. With the tap of the SYNC button Quick Sampling playback will wait until the next bar of the Style to begin, ensuring your sample starts at the exact right time.
LOOPER FUNCTION
Unleash Your Creativity.
Free up your hands during performances, practicing complex pieces, or building song sections by recording and looping chord progressions, drums patterns and musical phrases.
AUTO CHORD PLAY
Take Your Performance to the Next Level.
Expand your performance range with the convenient Auto Chord Play function with customizable chord progressions, which automatically plays back the predetermined chord progression while you’re playing a Style, freeing you up to solo or experiment – without worrying about playing the changes.
TRACK CONTROL
You’re In Control.
Empower creativity and transform your keyboard into a versatile instrument for producing professional-quality music with Track Control.
・ TRACK ON/OFF: Seamlessly shape your sound by muting or unmuting individual parts of a preset Style. Transition smoothly between song sections without needing to Switch styles, creating dynamic and expressive performances.
・ REVOICE: Effortlessly tailor any track to suit your musical vision. Change instrument Voices on tracks that may not match your composition, maintaining a rich, layered accompaniment without compromising depth.
・ VOLUME Setting: Achieve perfect harmony by adjusting the volume balance across tracks. Personalize the sound to match your preferences, ensuring every note resonates just right.
A variety of connectivity options provide all the support you need for practicing, playing, and performing. Plug in a microphone to try your hand at singing while playing, use the Rec'n'Share app to share your music with the world, and hook into PA systems to perform on stage.
・ USB TO DEVICE: Store/Load various data to/from USB devices.
・ USB TO HOST (USB-C): Send/Receive audio and MIDI data to/from computers and smart devices.
・ Individual L/R output: Connect to PA systems and studio equipment.
・ Foot Switch: Use a sustain pedal to control sounds.
| Size / Weight | ||
|---|---|---|
| Dimensions | Width | 992 mm (39-1/16”) |
| Height | 136 mm (5-3/8”) | |
| Depth | 404 mm (15-7/8”) | |
| Weight | Weight | 7.3 kg (16 lb, 1 oz) (not including batteries) |
| Packing Box | ||
| Width | 1068 mm (42-1/16") | |
| Height | 216 mm (8-1/2") | |
| Depth | 500 mm (19-11/16") | |
| Control Interface | ||
| Keyboard | Number of Keys | 61 |
| Type | Organ-Style | |
| Touch Response | Yes (Soft, Medium, Hard, Off) | |
| Display | Type | LCD |
| Backlight | Yes | |
| Language | English | |
| Panel | Language | English |
| Other Controllers | Pitch Bend | Yes |
| Modulation | Yes | |
| Art. Switches | Yes | |
| Control Knobs | 2 | |
| Voices | ||
| Tone Generation | Tone Generating Technology | AWM Stereo Sampling |
| Polyphony | Number of Polyphony (Max.) | 64 |
| Preset | Number of Voices | 890 (352 Voices + 40 Drum/SFXKits + 40 Arpeggio Voices + 458 XGlite Voices) |
| Featured Voices | 19 S.Art Lite Voices | |
| Compatibility | GM | Yes |
| XGlite | Yes | |
| Accompaniment Styles | ||
| Preset | Number of Preset Styles | 345 |
| Fingering | Multi Finger, Smart Chord | |
| Style Control | ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN A, MAIN B, TRACK ON/OFF | |
| Other Features | One Touch Setting (OTS) | Yes |
| Auto Chord Play | 100 Chord Progressions + 10 USER Chord Progressions | |
| Expandability | Expansion Style | 10 |
| Compatibility | Style File Format | (SFF) |
| Effects | ||
| Types | DSP | DSP1: 41 types + DSP2: 12 types |
| Motion Effect | 57 types | |
| Reverb | 15 types | |
| Chorus | 7 types | |
| Master EQ | 5 types | |
| Functions | ||
| Dual / Layers | Yes | |
| Split | Yes | |
| Melody Suppressor | Yes | |
| Harmony / Echo | 26 types | |
| Arpeggio | 164 types | |
| Songs | ||
| Preset | Number of Preset Songs | 2 |
| Recording | Number of Songs | 10 |
| Number of Tracks | 6 (5 Melody + 1 Style) | |
| Data Capacity | Approx. 19,000 notes (total for all 10 Songs) | |
| Compatible Data Format | Playback | SMF (Formats 0 & 1) |
| Recording | Original File Format (SMF 0 conversion function) | |
| USB Audio Recorder | ||
| Recording Time (max.) | 80 minutes (approx. 0.9 GB) per Song | |
| Format | Playback | WAV (44.1 kHz, 16-bit, stereo) |
| Recording | WAV (44.1 kHz, 16-bit, stereo) | |
| Quick Sampling | ||
| Sampling Type | Oneshot, Loop | |
| Samples (Preset/User) | 4 | |
| Sampling Time | Approx. 9.6 sec | |
| Sampling Sources | AUX IN, MIC INPUT, USB audio interface, WAV format files | |
| Sampling Format | Original File Format (16-bit, stereo) | |
| Sampling Rate | 44.1 kHz | |
| Storage and Connectivity | ||
| Internal Memory | Approx. 1.72 MB | |
| External Drives | USB flash drive | |
| Connectivity | DC IN | 16 V |
| AUX IN | Stereo mini jack × 1 | |
| Headphones | Standard stereo phone jack × 1 | |
| Foot Switch | Yes | |
| Expression Pedal | Yes | |
| USB TO DEVICE | Yes (USB Type-A) | |
| USB TO HOST | Yes (USB Type-C™) | |
| LINE OUT | Standard stereo phone jacks: L/L+R, R | |
| Microphone | Standard stereo phone jack x 1 | |
| Sound System | ||
| Amplifiers | 12 W x 2 | |
| Speakers | 12 cm x 2 | |
| Power Supply | ||
| Adaptors | PA-300C (Output : DC 16 V, 2.4 A) | |
| Batteries | Six “AA” size alkaline (LR6), manganese (R6) or Ni-MH rechargeable batteries | |
| Power Consumption | 13 W (When using PA-300C AC adaptor) | |
| Auto Power Off Function | Yes (Disabled/5/10/15/30/60/120 minutes) | |
| Accessories | ||
| Included Accessories | Owner’s Manual, Music Rest, AC adaptor PA-300C*, Power Cord* (* May not be included depending on your area. Check with your Yamaha dealer.) | |
