Product Code:DHR12
Yamaha DHR12 Powered Loudspeaker
- The DHR12 is a 2-way bi-amp powered loudspeaker equipped with a 12-inch woofer and a 1.4-inch HF driver, perfect for use as a main or utility speaker.
- Brand:
*only3 item(s) remaining
-
AED 3,177.30
- -
- +
*Rate inclusive of VAT. Delivery time: 2 - 4 days
The DHR12 is a 2-way bi-amp powered loudspeaker equipped with a 12-inch woofer and a 1.4-inch HF driver, perfect for use as a main or utility speaker. Combining a 1000W amplifier and high-performance DSP with the same plywood construction found on Yamaha’s high-end DZR Series, the DHR12 offers best-in-class sound quality and durability.
FEATURES
Featuring a plywood cabinet that delivers a clear sound with minimal vibration
Plywood enclosure with a polyurea coating for a robust, scratch resistant surface
Compact size despite the 12-inch LF driver that provides excellent low frequency response
Can be installed in a horizontal or vertical configuration with a rotatable HF horn offering the flexibility needed for installation in a wide range of environments
Optional UB-DXRDHR12 U-bracket allows both for vertical or horizontal use
Dual-angle pole sockets offer both 0° or a -7° down tilt
Rigging points for use with eye bolts
Proprietary FIR-X™ tuning, provides FIR filtering and corrective EQ, minimizing phase distortion
| DHR12 | ||
|---|---|---|
| Speaker type | 2-way, Bi-amped Powered Speaker, Bass-reflex | |
| Frequency range (-10dB) | 48 Hz - 20 kHz | |
| Coverage area | H90ﾟ x V60ﾟ (Rotatable) | |
| Crossover | 1.8 kHz: FIR-X tuning™ (linear phase FIR filter) | |
| Maximum Output Level (Measured peak, IEC noise@1m) | 130 dB SPL | |
| Components | LF | Diameter: 12" cone, Voice Coil: 2.5", Magnet: Ferrite |
| HF | Diaphragm: 1.4", Type: 1" throat compression driver, Magnet: Ferrite | |
| Amplifier class | Class-D | |
| Power rating | Dynamic | 1000 W (LF: 800 W, HF: 200 W) *1 |
| Continuous | 465 W (LF: 400 W, HF: 65 W) | |
| Cooling | Fan cooling, 4 speeds | |
| Power consumption | 74 W (1/8power), 18 W (Idle) | |
| Power requirements | 100 V, 100-120 V, 220-240 V, 110/127/220 V (Brazil), 50/60 Hz | |
| A/D D/A Converters | 24 bit 48 kHz Sampling | |
| Processors | OFF, 100 Hz, 120 Hz, 24 dB/Oct.; D-CONTOUR: FOH/MAIN, MONITOR, OFF | |
| I/O connectors | INPUT1: Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix) | |
| Cabinet material | Plywood | |
| Finish | Durable Polyurea Painting, Black | |
| Handle | Top x1 Side x2 | |
| Pole socket | Φ35 mm x2 (Bottom,0° or -7°) |
|
| Rigging | Top x 2, Rear x 1 (Fit for M10 x 30 - 50 mm Eyebolts) | |
| Floor Monitor Angle | - | |
| Dimensions | W | 359 mm (14.1") |
| H | 578 mm (22.8") (with rubber feet) | |
| D | 340 mm (13.4") | |
| Net weight | 19.2 kg (42.3 lbs) | |
| Options | U-bracket: UB-DXRDHR12 | |
