2-in/2-out USB-C Audio/MIDI Interface with 32-bit/192 kHz support, 2 combo inputs, DSP-powered mixing and effects for smooth creative workflow.
FEATURES
USB Type-C Audio/MIDI Interface with 32-bit integer / 192 kHz support
MIDI input and output
2 D-PRE mic preamps with +48 V phantom power and Mono switch
2 Mic/Line Combo inputs: XLR / 6.3 mm jack - Hi-Z switch on input 2 for electric guitar
2 TRS line outputs, 1 Headphones output
Input mixing channels: 2 mono + 3 stereo loopback + 1 FX
Busses: 1 MIX (Stereo) + 1 FX + 1 STEREO
Three-channel loopback enables flexible streaming and communication setups.
Effects powered by the internal DSP and Basic FX Suite give your sound a professional finish.
Latency-free DSP monitoring with FX for enhanced performance
Sturdy metal housing
Includes Cubase AI for PC, Cubasis LE DAW app for iPhone/iPad, Steinberg Plus and USB cable
USB 3.0 power supply (optional power supply for USB 2.0 required)
Dimensions (W x H x D): 159 x 47 x 159 mm (6.3" x 1.9” x 6.3”)
Net weight: 1.0 kg (2.0 lb)
| General Specifications | |
|---|---|
| Analog Input | 2 Mic/Line Combo inputs (Hi-Z switch on Input 2 for electric guitar) |
| Analog Output | 2 TRS |
| USB TO HOST | 1 (USB Type-C, 32-bit) |
| Phones | 1 TRS (15 mW + 15 mW @ 40 Ohm) |
| DC Power | 2 (Type-C USB bus power or Type-A micro-USB DC IN) |
| MIDI | 1 IN / 1 OUT |
| User Interface | Dedicated software "dspMixFx", Input Gain, Mono/Stereo Switch, Hi-Z for Input 2, +48V Phantom Power, Mix Balance, Main Volume, Headphones Volume |
| Recording & Playback | 2-track recording, 2-track playback (USB) |
| Sampling Frequency Rate | 192 kHz - 44.1 kHz |
| Frequency Response | +0.0 / -0.4 dB (20 Hz to 22 kHz) |
| Total Harmonic Distortion | [MIC/LINE/Hi-Z] 0.003% at 1 kHz, 22 Hz/22 kHz BPF; [MAIN OUTPUT] 0.002% at 1 kHz, 22 Hz/22 kHz BPF |
| Dynamic Range | [MIC/LINE/Hi-Z] 102 dB; [MAIN OUTPUT] 105 dB |
| Gain Range | 54 dB |
| Power Requirements | DC 5 V / 0.9 A |
| Power Consumption | 4.5 W |
| Dimensions (W × H × D) | 159 mm × 47 mm × 159 mm (6.3" × 1.9" × 6.3") |
| Net Weight | 1.0 kg (2.0 lb) |
| Included Accessories | Setup Guide, Cubase AI License Card, Basic FX Suite License Card, Steinberg Plus License Card, USB Cable (3.1 Gen1, Type-C to Type-A, 1.0 m) |
| Operating Temperature | 0 to +40 °C |
| Mixing Capacity / DSP | |
| Input Channels | 2 Mono + 3 Stereo Loopback + 1 FX |
| Mix Buses | 2 (1 MIX + 1 Streaming Mix) |
| Stereo Buses | 1 |
| FX Buses | 1 |
| On-board DSP Processors | Gate, Compressor, Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), Pitch Fix (Voice Changer), Ducker, Multi-Band Compressor, Compander, Delay, REV-X (Reverb) |
