Marantz MODEL M1 - 2 Channel Wireless Streaming Amplifier - Black
- MODEL M1 is a wireless streaming amplifier engineered with performance and versatility in mind.
- Brand:
- Product Code:MODELM1N1B
MODEL M1 is a wireless streaming amplifier engineered with performance and versatility in mind. Enjoy your favorite music or TV shows with seamless connectivity from one elegant, compact device.
FEATURES
Crafted in Shirakawa, Japan
2.1 Channels
100 Watts per Channel
HDMI eARC
Dolby Digital+
HEOS Built-in
| Amplifier | |
|---|---|
| Power Amplifier Rated output & THD (8 ohm) | 100 W+100 W (8 Ω, THD 0.05%) |
| Power Amplifier Rated output & THD (4 ohm) | 125 W + 125 W (4Ω, 1 kHz, T.H.D. 0.05%) |
| Frequency Response | 20 Hz to 20 kHz : ±1 dB |
| Connected Loudspeaker Impedance | 4 – 16 Ω |
| Audio Inputs / Outputs | |
| Loudspeaker Binding Posts | 4-way binding posts |
| Digital Inputs | HDMI (eARC), TOSLINK |
| Analog Inputs | RCA L/R |
| Subwoofer Out | RCA Mono |
| Inputs Audio Options | |
| Channel Assignments | Stereo (Default), Dual Mono |
| Volume Limit | 80–100% |
| Balance | -15 dB to +15 dB |
| Adjustable High Pass / Low Pass Filters | 40–250 Hz / 40–120 Hz |
| EQ | Bass, Treble -5 dB to +5 dB |
| Sound Modes | Stereo, Direct, Virtual, Dialog Enhancer, Night Mode |
| TV Sound Grouping | Yes |
| Audio Format Support | |
| Decoding | Dolby Digital +, Dolby Digital, LPCM, DSD |
| Stereo PCM / Multi-channel PCM | Yes / Yes |
| Stereo File Formats (HEOS network share or USB) | WMA (up to 192 kbps), AAC & MP3 (up to 320 kbps), WAV, ALAC, FLAC (up to 24-bit/192 kHz), DSD (2.8 MHz, 5.6 MHz) |
| Streaming Technologies | |
| Bluetooth Receive | BT 4.2.X |
| Bluetooth Transmit | No |
| AirPlay | AirPlay 2 |
| Spotify | Spotify Connect |
| Music Services and Sources | |
| Music Services Supported | Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, Tidal, Tidal HiRes, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, QPlay, SoundCloud |
| Music Stored on Mobile Device | Yes (iOS, Android or Kindle Fire) |
| NAS (Network Attached Storage) | Network share |
| USB Storage Device Playback | Yes (FAT32, NTFS formatted drives) |
| Networking & Control | |
| Wired Connectivity | Ethernet |
| Wireless Connectivity | Dual band, 802.11 a/b/g/n/ac |
| IR Input | 3.5mm |
| IR Learning | Yes |
| Control System Compatibility via TCP/IP | Creston, Control4, AMX |
| HEOS® App | iOS, Android, Kindle Fire |
| General | |
| Product Color | Black |
| User Interface | Volume up/down, Play/Pause, Multi-colored LED status indicator, Connect button (rear), Bluetooth button (rear) |
| Dimensions (W x D x H) Inches | 9.41 x 3.31 x 8.54 |
| Dimensions (W x D x H) mm | 239 x 84 x 217 |
| Weight (lbs) | 4.84 |
| Weight (kg) | 2.2 |
