Unleash the full potential of your pedal board! The Switchboard Effects Operator is a streamlined and compact effects switching solution with a remarkably simple interface, bringing complete signal path control, multi-pedal preset recall, and convenient effects switching right to your feet.
Features
- 5 relay true bypass effects loops
- 400 easily accessible presets with an additional 100 favorite presets
- Large, full color LCD screen and Encoder knob provide easy-to-use graphic UI
- Completely rearrangeable effects loop order
- Programable footswitch and MIDI outputs for controlling outboard gear
- Integrated professional tuner
- Built-in moveable volume pedal
- Switchable high-fidelity input and output buffers
- Stereo capable loop 5 can host stereo effect
Specs
- Included Accessories: International voltage 9V adaptor
- Connectivity: USB-C®
- Input Impedance: 1 MΩ
- Inputs: One - 1/4"
- Output Impedance: 150Ω
- Power Consumption: 500mA
- Power Requirements: 9VDC Center Negative AC Adapter
- Material: Anodized Aluminum
- Product Name: Fender Switchboard Effects Operator
- Series: Switchers and Controllers
- Product Depth: 4.53” (115 mm)
- Product Height: 2.75" (70 mm)
- Product Width: 9.53" (242 mm)
- Case Pack Quantity: 6
- Commodity Code: 8543709099
