Harkening back to the late '80s when Charvel guitars were manufactured exclusively in Japan, we proudly introduce the all-new Guthrie Govan Signature MJ San Dimas® SD24 CM. Exquisite in style, this MJ signature model blends Charvel's unparalleled legacy of designing high-performance instruments with an assortment of Govan's preferred top-end features.
This 25.5" scale guitar features a San Dimas® basswood body with an ash top and specially contoured heel (sans neck plate) for easy access to the upper reaches of the fingerboard. The bolt-on maple neck has a "caramelized" heat and drying treatment that makes it sound and feel much older, along with graphite reinforcement, satin finish on the back of the neck and a conveniently located heel-mount truss rod adjustment wheel. Most unusually for a San Dimas model, the 12"-16" compound radius caramelized maple fingerboard features 24 jumbo stainless-steel frets, as well as crème dot inlays and Luminlay® side dots.
Other premium features include three specially wound Charvel custom pickups arranged in a versatile HSH configuration with five-way switching for the expansive tonal openness and dynamic sensitivity that Govan demands, along with a two-way mini toggle switch to engage single-coil simulation in bridge and neck humbucker positions. This instrument also comes loaded with two Luminlay numbered dome control knobs for volume and tone, recessed Charvel locking tremolo bridge with pop-in tremolo arm and brass block, Gotoh® die-cast locking tuners and Graph Tech® TUSQ® XL nut.
The Guthrie Govan Signature MJ San Dimas® SD24 CM is available in a stately Three-Tone Sunburst finish, complete with chrome hardware, brown pickup bobbins and a licensed Fender® Stratocaster® headstock.
Features
General | |
---|---|
Series | MJ |
Orientation | Right-Hand |
Color | Three-Tone Sunburst |
Country Of Origin | JP |
Neck | |
Headstock | Licensed Fender Stratocaster |
Neck Material | Caramelized Maple |
Neck Finish | Satin |
Neck Shape | Speed Neck with Rolled Fingerboard Edges |
Neck Construction | Bolt-On with Graphite Reinforcement |
Fingerboard Radius | 12"-16" Compound Radius (304.8 mm to 406.4 mm) |
Fingerboard Material | Caramelized Maple |
Position Inlays | Crème Dots |
Side Dots | Luminlay |
Number of Frets | 24 |
Truss Rod Nut | Heel-Mount Truss Rod Adjustment Wheel |
String Nut | Graph Tech TUSQ XL |
Nut Width | 1.6875" (42.86 mm) |
Nut Material | Graph Tech TUSQ XL |
Body | |
Body | Basswood |
Body Finish | Satin |
Body Shape | San Dimas Style 1 |
Body Top | Ash |
Body Material | Basswood |
Hardware | |
Bridge | Recessed Charvel Locking Tremolo Bridge |
Tremolo Block | Brass |
Pickup Covers | Brown |
Control Knobs | Dome-Style Luminlay Numbered |
Switch Tip | Black |
Hardware Finish | Chrome |
Tuning Machines | Gotoh Locking |
Strings | Nickel Plated Steel (.010-.046 Gauges) |
Tremolo Arm | Pop-In Tremolo Arm |
Neck Plate | None - 4-Bolt Sculpted Heel |
Strap Buttons | Standard |
Electronics | |
Bridge Pickup | Charvel Custom Humbucking |
Middle Pickup | Charvel Custom Single-Coil |
Neck Pickup | Charvel Custom Humbucking |
Pickup Configuration | HSH |
Controls | Volume, Tone |
Switching |
5-Position Blade: Position 1. Full Bridge Pickup Position 2. Bridge Inner Coil and Middle Pickup Position 3. Bridge Outer Coil and Neck Outer Coil Position 4. Middle and Neck Outer Coil Position 5. Full Neck Pickup |
Auxiliary Switching | 2-Way Mini-Toggle to Engage Single-Coil Simulation in Bridge (Pos 1) and Neck (Pos 5) Humbucker Positions |
Measurements | |
Dimensions | 5.00x16.00x42.00 IN |
Shipping Weight | 11.00 LB |
Fret Size | Jumbo Stainless Steel |
Scale Length | 25.5" (64.77 cm) |
Shipping Length | 42.00 IN |
Shipping Height | 5.00 IN |
Shipping Width | 16.00 IN |
Miscellaneous | |
Unique Features | Side Mounted Jack, Luminlay® side-dots |
