Product Code:PF000612

Powersoft MEZZO 324 A 320W/4-channel Compact Amplifier with DSP

  • Mezzo 324 A heralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size.
  • Brand:
*Out of Stock
  • AED 4,165.35

  • -
  • +
*Rate inclusive of VAT. Delivery time: 2 - 4 days

Mezzo 324 A heralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size. Exceedingly flexible, “A” versions of Mezzo offer remote control and monitoring of all the vital functions. The small form factor allows it to be mounted anywhere thanks to the included mounting kit. The 320 W versions of Mezzo can also be mounted in air handling spaces, such as double ceilings or wall boxes.

MyPowersoft services are available for this product.

FEATURES

  • Multiple mounting options
  • Auto-Setup
  • Power-sharing
  • Full remote control via 3rd party controls
General
Output Power per Channel
Output Power per Channel80 W @ 2 Ω / 80 W @ 4 Ω / 80 W @ 8 Ω
Maximum Power-Sharing Capacity per Channel320 W @ 4 Ω / 320 W @ 8 Ω
Max Output Voltage / Current
Maximum Unclipped Output Voltage142 Vpeak
Maximum Output Current15.6 Apeak
AC Main Power
Power SupplyUniversal, regulated switch mode with PFC (Power Factor Correction)
Nominal Power Requirement100-240 V ±10%, 50-60 Hz
Operating Voltage90 V – 264 V
Power Consumption / Current Draw
Idle115 V: 15 W – 0.25 A / 230 V: 16 W – 0.18 A
1/8 of Max Output Power @ 4 Ω115 V: 76 W – 0.71 A / 230 V: 78 W – 0.43 A
THERMAL
Thermal Dissipation (Idle)115 V: 90 BTU/h / 230 V: 54 BTU/h
Thermal Dissipation (1/8 Max @ 4 Ω)115 V: 50 BTU/h / 230 V: 102 BTU/h
