Product Code:2962411500
Featuring a sculpted shredder's cut heel and a scalloped lower back bout for easy upper access to the fingerboard, the alder body in the classic Dinky style is cloaked in several stage-stealing finishes - Gloss Black, Matte Blue Frost, Satin Burgundy Mist or Three-Tone Sunburst.
The bolt-on caramelized maple "speed" neck has graphite reinforcement, silky-smooth hand-rubbed urethane back finish, heel-mount truss rod adjustment wheel and Luminlay side dots. Its 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 24 jumbo frets, pearloid dot inlays and Graph Tech TUSQ XL nut.
Brimming with versatility courtesy of the mini two-way toggle switch for series and parallel, this axe features an HH pickup configuration consisting of a direct mount Custom Seymour Duncan® Full Shred TB-10 bridge pickup and direct mount Seymour Duncan Alnico II Pro APH-1N neck pickup. The bridge pickup radiates a crisp top-end with low-end articulation, while the neck pickup has incredible range with soaring highs and silky lows.
Blending sophisticated style with assertive tone, the DK24 HH 2PT CM also offers premium modern features such as a five-way blade pickup switch, Stratocaster-style skirt knobs for the volume (with 500K EVH Bourns low-friction potentiometer) and no-load tone controls, Gotoh Custom 510 recessed tremolo bridge, locking tuners, chrome hardware and more.
Features
General | |
---|---|
Series | Pro-Mod |
Orientation | Right-Hand |
Color | Malibu Sunset |
Country Of Origin | MX |
Neck | |
Headstock | Licensed Fender Stratocaster |
Neck Material | Caramelized Maple |
Neck Finish | Hand-Rubbed Urethane |
Neck Shape | Speed Neck with Rolled Fingerboard Edges |
Neck Construction | Bolt-On with Graphite Reinforcement |
Fingerboard Radius | 12"-16" Compound Radius (304.8 mm to 406.4 mm) |
Fingerboard Material | Caramelized Maple |
Position Inlays | 4mm Pearloid Dot |
Side Dots | Luminlay |
Number of Frets | 24 |
Truss Rod | Dual-Action with Wheel |
Truss Rod Nut | Heel-Mount Truss Rod Adjustment Wheel |
String Nut | Graph Tech TUSQ XL |
Nut Width | 1.6875" (42.86 mm) |
Nut Material | Graph Tech TUSQ XL |
Body | |
Body | Alder |
Body Finish | Gloss |
Body Shape | Dinky |
Body Style | Solid Body |
Body Material | Alder |
Hardware | |
Bridge | Gotoh Custom 510 Tremolo |
Pickguard | None |
Pickup Covers | Black |
Control Knobs | Strat-Style Skirt |
Switch Tip | Black |
Hardware Finish | Chrome |
Tuning Machines | Charvel-Branded Die-Cast Locking |
String Trees | Fender Standard String Guide |
Strings | Nickel Plated Steel (.009-.042 Gauges) |
Tremolo Arm | Gotoh |
Neck Plate | None - 4-Bolt Sculpted Heel |
Strap Buttons | Standard |
Electronics | |
Bridge Pickup | Seymour Duncan Full Shred™ TB-10 |
Neck Pickup | Seymour Duncan Alnico II Pro™ APH-1N |
Pickup Configuration | HH |
Controls | Volume (500K EVH Bourns Low Friction Pot), No-Load Tone |
Switching | 5-Position Blade: Position 1. Bridge Pickup, Position 2. Both Outer Coils, Position 3. Bridge and Neck Pickup, Position 4. Both Inside Coils, Position 5. Neck Pickup |
Auxiliary Switching | 2-Position Mini Toggle Down/All Series, Up/All Parallel |
Measurements | |
Dimensions | 4.50 x 15.20 x 42.90 IN |
Shipping Weight | 10.70 LB |
Fret Size | Jumbo |
Scale Length | 25.5" (64.77 cm) |
Shipping Length | 42.90 IN |
Shipping Height | 4.50 IN |
Shipping Width | 15.20 IN |
Accessories | |
Saddle Height Wrench | Yes |
Miscellaneous | |
Disclaimer | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
Commodity Code | 9207.90.0040 |
Unique Features | Luminlay Side Dots |
